Kiosk connection box with integrated scanner and printer, ideal for VSEs. It includes an optional Vesa 200x200 card reader. It offers 3 USB ports, a bi-directional One Connect (44 Pin) port, and external control via RS232C and RJ45. The integrated thermal printer offers a print speed of 250mm/sec and supports 80mm paper rolls. The barcode/QR code reader reads telephone screens and printed barcodes. Dimensions: 334.4 x 389.6 x 236.5 mm. Weight: 7.4 kg. Sold only with KM24A.
Security policy Your personal data is 100% protected
Delivery policy 2 to 3 business days in France, 2 to 5 business days in Europe
Return policy 30 days in case of issues
Kiosk connection box (scanner and printer integrated into One Connect port)
Electronic payment terminal and card reader with Vesa 200 x 200 option
NB: This product is sold only with KM24A
Connectivity:
Input ports: 3 USB ports
Output port: 1 Touch Out port
Two-way connector: One Connect port (44-pin)
External control: 1 RS232C port, 1 RJ45 port (IN)
Printing:
Printing type: Thermal
Print speed: 250 mm/second
Cutting: Automatic
Paper support: 80 mm roll
Bar code reader/QR codes:
Reading formats: 1D, 2D
Reading: Phone screen and printed barcodes
Supported formats: UPC-A, UPC-E, EAN-8, EAN-13, Code 128, Code 39, Code 93, Interleaved 2 of 5, GS1 DataBar, Codabar, QR
Physical features:
Product dimensions: 334.4 x 389.6 x 236.5 mm
Dimensions with packaging: 428 x 471 x 316 mm
Product weight: 7.4 kg
Weight with packaging: 9.1 kg
check_circle
check_circle
SAMSUNG CYKM24CPX Boitier kiosk Samsung CY-KM24CPX for Kiosk KM24A
Kiosk connection box with integrated scanner and printer, ideal for VSEs. It includes an optional Vesa 200x200 card reader. It offers 3 USB ports, a bi-directional One Connect (44 Pin) port, and external control via RS232C and RJ45. The integrated thermal printer offers a print speed of 250mm/sec and supports 80mm paper rolls. The barcode/QR code reader reads telephone screens and printed barcodes. Dimensions: 334.4 x 389.6 x 236.5 mm. Weight: 7.4 kg. Sold only with KM24A.
